This PR adds a possibility to adjust roundness of trace bar corners.
Each corners roundness can be adjusted individually.
Value passed represents percentage of desirable roundness.
"cornerroundness": { "bottomleft": 0.3, "bottomright": 0, "topleft": 0.3, "topright": 0 }
This is implemented by taking calculated vector values in bar\plot.js file and adjusting them when generating svg path description attribute.
Round corners are drawn with absolute elliptical arc curve command A.
Arc radius is calculated by taking the smallest edge width of all bars and dividing it by two and then applying desired roundness percentage value.
All four possible vector drawing directions are handled.
